Description
Capacity 25* – 50 – 75 – 100 – 150 – 200 – 250 kg
Up to 6000 divisions OIML-R60
Fully stainless steel
Protected against humidity IP-67
Platform up to 500×500 mm
High accuracy with off-center loads
Technical data
| Accuracy class | C3-C6 |
| Rated output | 2 ± 10% mV/V |
| Vmin | Emax/12000 |
| Excitation Voltage | 5÷15V |
| Input Resistance | 390 ± 3Ω |
| Output Resistance | 350 ± 3Ω |
| Temperature Compensation | -10ºC/+40ºC |
| Temperature limits | -30ºC/ +70ºC |
| Insulation resistance | > 5000 MΩ |
* Capacities out of CE Certificate
