Description
Capacity (BL) 7* – 10 – 20 – 40 Kg
Capacity (BL-C) 10 – 18 – 36 Kg
Up to 6000 divisions OIML-R60
Fully stainless steel
Protected against humidity IP-67
Platform up to 380×380 mm
High accuracy with off-center loads
Technical data
| Accuracy class | C3-C6 |
| Rated output | 2 ± 0.1% mV/V |
| Vmin | Emax/18000 |
| Excitation Voltage | 5÷15V |
| Input Resistance | 390 ± 3Ω |
| Output Resistance | 350 ± 3Ω |
| Temperature Compensation | -10ºC/+40ºC |
| Temperature limits | -30ºC/ +70ºC |
| Insulation resistance | > 5000 MΩ |
* Capacities out of CE Certificate
